Nektar++ configuration and build¶
In the following we will provide an example on how to configure and build Nektar++ on a remote machine.
Nektar++ on ARCHER2¶
After being successfully logged into the cluster, first export the following and load modules:
export CRAY_ADD_RPATH=yes module swap PrgEnv-cray PrgEnv-gnu module load cray-fftw module load cmake
Enter the work directory (/work) and clone the Nektar++ code into a folder, e.g. nektarpp
cd /work/e01/e01/mlahooti git clone https://gitlab.nektar.info/nektar/nektar.git nektarpp
- After the code is cloned, enter the nektarpp folder, make a build directory and enter it
cd nektarpp mkdir build cd build
- From within the build directory, run the configure command. Note the use of CC and CXX to select the special ARCHER-specific compilers.
CC=cc CXX=CC cmake -DNEKTAR_USE_SYSTEM_BLAS_LAPACK=OFF -DNEKTAR_USE_MPI=ON -DNEKTAR_USE_HDF5=ON -DNEKTAR_USE_FFTW=ON -DTHIRDPARTY_BUILD_BOOST=ON -DTHIRDPARTY_BUILD_HDF5=ON ..
cc and CC are the C and C++ wrappers for the Cray utilities and determined by the PrgEnv module. SYSTEM_BLAS_LAPACK is disabled since, by default, we can use the libsci package which contains an optimized version of BLAS and LAPACK and not require any additional arguments to cc. HDF5 is a better output option to use on ARCHER2 since often we run out of the number of files limit on the quota. Setting this option from within ccmake has led to problems however so make sure to specify it on the cmake command line as above. Further, the HDF5 version on the ARCHER2 is not supported at the moment, so here it is built as a third-party library. They are currently not using the system boost since it does not appear to be using C++11 and so causing compilation errors. At this point you can run ccmake .. to e.g. disable unnecessary solvers. Now run make as usual to compile the code
make -j 4 install
- For more detailed approach please visit:
https://www.nektar.info/nektar-on-archer2/
FabNEPTUNE Installation¶
Before being able to run FabNEPTUNE [with the assumption that you have been able to run the basic FabSim examples described in the other documentation files, and that you have configured and built Nektar++ (https://www.nektar.info/) on the target machine, and successfully tested the executable code!], you should install FabNEPTUNE inside of FabSim3. This will provide functionality to extend FabSim3’s workflow and remote submission capabilities to NEPTUNE specific tasks.
To install FabSim3 tool, please follow the installation from https://fabsim3.readthedocs.io/en/latest/installation/
To install FabNEPTUNE plugin, simply type:
fabsim localhost install_plugin:FabNEPTUNE
After installation of FabNEPTUNE the following need to be done.
Custom Environments¶
Regardless of the existing python environment on the HPC/local system, you need to setup a custom Python environment including packages that are not in the central installation, the simplest approach here would be the installation of Miniconda locally in your own directories.
Installing Miniconda¶
First, you should download Miniconda (links to the various miniconda versions on the Miniconda website: https://docs.conda.io/en/latest/miniconda.html)
Note
If you wish to use Python on the Archer2’s compute nodes then you must install Miniconda in your /work directories as these are the only ones visible on the compute nodes.
Once you have downloaded the installer, you can run it. For example:
user@login*:~> bash Miniconda3-latest-Linux-x86_64.sh
After you have installed Miniconda and setup your environment to access it, you can install whatever packages you wish using the conda install … command. For example:
(base)user@login*:~> conda install somepy
Installing EasyVVUQ¶
Next you need to install EasyVVUQ in your Miniconda environment to access it. You can install EasyVVUQ using:
(base)user@login*:~> pip install easyvvuq
- and upgrade the library using:
(base)user@login*:~> pip install easyvvuq --upgrade
Where (base) can be replaced with your new conda environment
- For more detailed approach please visit:
https://github.com/UCL-CCS/EasyVVUQ
Installing EasySurrogate¶
Next you need to install EasySurrogate in your Miniconda environment to access it. You can install EasyVVUQ using:
(base)user@login*:~> pip install easysurrogate
Where (base) can be replaced with your new conda environment
- For more detailed approach please visit:
https://github.com/wedeling/EasySurrogate
Installing FabSim3¶
Next you need to install FabSim3 somewhere in your directories and your Miniconda environment to access it.
First you need to check if the following Python modules are already installed
fabric3==1.13.1.post1 PyYAML numpy ruamel.yaml rich
Then install both ruamel.yaml and rich package
pip3 install ruamel.yaml rich
Once you have installed the required packages, then clone FabSim3 from the GitHub repository:
git clone https://github.com/djgroen/FabSim3.git
Finally change to your FabSim3 directory, and type
(base)user@login*:~>python3 configure_fabsim.py
Where (base) can be replaced with your new conda environment
- For more detailed approach please visit:
https://github.com/djgroen/FabSim3
Installing QCG-PilotJob¶
Next you need to install QCG-PilotJob somewhere in your Miniconda environment to access it.
- You can install QCG-PilotJob using:
(base)user@login*:~> pip install qcg-pilotjob
- and supplementary packages can be installed using:
(base)user@login*:~> pip install qcg-pilotjob-cmds (base)user@login*:~> pip install qcg-pilotjob-executor-api
Where (base) can be replaced with your new conda environment
- For more detailed approach please visit:
https://github.com/vecma-project/QCG-PilotJob
Creating virtual environment¶
Finally you need to create a new virtual environment, and update the following files:
convection_2d_easyvvuq_init_run_analyse_local.py convection_2d_easyvvuq_init_run_analyse_remote.py Convection2D_init_run_analyse_campaign_local Convection2D_init_run_analyse_campaign_remote
which are found in plugins/FabNEPTUNE/config_files/convection_2d_easyvvuq_InRuAn*_QCGPJ and plugins/FabNEPTUNE/config_files/convection_2d_easyvvuq_easysurrogate_InRuAn*_DAS_QCGPJ and plugins/FabNEPTUNE/templates
This environment is used by EasyVVUQ campaign. For example if you want to execute the convection jobs on a remote machine do only the following:
First, open the file “convection_2d_easyvvuq_init_run_analyse_remote.py” and modify it with your path (your virtual environment)
... with QCGPJPool(template_params={'venv': '/mnt/lustre/a2fswork2/work/e723/e723/kevinb/venv_kevin'}) as qcgpj: campaign.execute(pool=qcgpj).collate(progress_bar=True) ...
and then open “FabNEPTUNE/templates/Convection2D_init_run_analyse_campaign_remote” and modify it with your path (your python environment)
... /mnt/lustre/a2fs-work2/work/e723/e723/kevinb/miniconda3/envs/py38/bin/python3.8 convection_2d_easyvvuq_init_run_analyse_remote.py $machine_name '$run_command_remote' $convection_2d_exec ...
Note
If you want to run FabNEPTUNE on your local machine and execute the convection jobs on a remote machine (e.g. fabsim archer2 …), you need to have the virtual environment on remote machine and you only need to have FabNEPTUNE installed on your local machine (no need for the additional installation of FabNEPTUNE on a remote machine!)
- You can install virtualenv using:
curl https://bootstrap.pypa.io/get-pip.py -o get-pip.py python3 get-pip.py --user pip install --user virtualenv
- Then to create private virtual environment type:
virtualenv venv . venv/bin/activate
Once you have installed the required packages and created virtual environment, then install QCG-PilotJob using:
pip install qcg-pilotjob
- and supplementary packages can be installed using:
pip install qcg-pilotjob-cmds pip install qcg-pilotjob-executor-api
- For more detailed approach please visit:
https://qcg-pilotjob.readthedocs.io/en/develop/installation.html
